Power over Ethernet

9 .. 50V DC

Design

Desktop

Operating mode

Client, AP Router, Access Point, Client Router (wisp), Cellular router

Wireless frequency

2.4 + 5 GHz (dual band), LTE, Bluetooth

WiFi standards

802.11n, 802.11a, 802.11b/g, 802.11ac - wave2

Transmission speed - 5GHz [Mb/s]

866

Transmission speed - 2.4GHz [Mb/s]

300

Security

WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Detachable

Detachable antennas

8

RF connectors

(3) RSMA female, (5) SMA female

Integrated 4G/LTE radio part

Yes

Power type

4-pin automotive

4G/LTE bands support

(1) 2100 MHz, (3) 1800 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (38) 2600 MHz, (40) 2300 MHz, (5) 850 MHz, (41) 2500 MHz, (28) 700 MHz, (32) 1500 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

4

LAN speed

(4) 10/100/1000Mbps + (1) 10/100/1000Mbps LAN/WAN

Max. power consumption [W]

22

Power via connector/terminal

9 .. 50V DC

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

540

Width [mm]

132

Height [mm]

44

Depth [mm]

95

CPU

ARM Cortex A7

CPU frequency [MHz]

717

SIM slot

Yes

SIM slots quantity

2

USB

Yes

IPv6 support

Yes

Default IP address

192.168.1.1

Internal storage [MB]

256

RAM [MB]

256

Default login and password

admin / admin01

GPS modul

Yes
