Huawei S220-24P4X Gigabit PoE switch, 4x SFP+

Huawei S220-24P4X Gigabit PoE switch, 4x SFP+
Your price incl. VAT (20.0%)
1,674.23 RON
✅ În stoc < 10 Бр.
Delivery Data de livrare planificată prin curier către dvs 05-03-2025
Manufacturer
Huawei
Product number
S220-24P4X
Product Code
RL027.631
Warranty
36 months

Having a question?
You have a choice of 2 variants
Huawei S220-24T4X Gigabit switch, 4x SFP+
S220-24T4X
810.10 RON excl. VAT
Huawei S220-24P4X Gigabit PoE switch, 4x SFP+
S220-24P4X
1,395.19 RON excl. VAT
MaxLink 10G SFP+ optical module, MM, 850nm, 300m, 2x LC connector, DDM
MaxLink 10G SFP+ optical module, MM, 850nm, 300m, 2x LC connector, DDMML-S+85D-03
31.75 RON excl. VAT
Masterlan patch cable UTP, Cat5e, 1m, yellow
Masterlan patch cable UTP, Cat5e, 1m, yellowPCU5E-1YW-MS
1.82 RON excl. VAT
Gembird Power cord 230V, 1,8m, angled
Gembird Power cord 230V, 1,8m, angledPC-186A-VDE
17.60 RON excl. VAT
MaxLink 10G SFP+ optical module, SM, 1310nm, 10km, 2x LC connector, DDM
MaxLink 10G SFP+ optical module, SM, 1310nm, 10km, 2x LC connector, DDMML-S+31D-10
49.94 RON excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDM
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
66.70 RON excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDM
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
66.70 RON excl. VAT
Masterlan comfort patch cable UTP, Cat5e, 5m, gray
Masterlan comfort patch cable UTP, Cat5e, 5m, grayPCU5E-5-MSC
10.25 RON excl. VAT

Download

https://download.discomp.cz/Huawei/Datasheets/Huawei_eKitEngine_S220_Series_Switch.pdf
Download Datasheet

Technical parameters

LAN ports
Design
Rackmount, Desktop, On the wall
Packet forwarding rate [Mpps]
95
Switchning capacity [Gbps]
128
MAC address table
16000
Web management
Yes
Management
SSH, Telnet, Web management
Features
DHCP snooping, QoS, VLAN
Power type
Mains power (230V)
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
SFP+ cages
4
Optical interfaces
(4) 10Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
24
PoE budget [W]
400
Max. power consumption [W]
486
Serial port
RJ45
Chassis design
Metal
Power via connector/terminal
230V AC
Buttons
Reset, mode
Operating temperature [°C]
-5 up to 50
Depth [mm]
220
Width [mm]
442
Height [mm]
44
Default IP address
192.168.1.1
Default login and password
admin / admin
