Grandstream GWN7803P Layer 2+ Managed Network PoE Switch 24 ports / 4 SFP
Your price incl. VAT (20.0%)
1,409.90 RON
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 27-11-2024
1373.60 RON excl. VAT
1609.40 RON excl. VAT
Product description
The GWN7800 series are Layer 2+ managed network switches that allow small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable.
Key features
- 24 Gigabit Ethernet ports and 4 Gigabit SFP ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
- Supports deployment in IPv6 and IPv4 networks
- Provides quaternary binding of IP, MAC, VLAN, ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Local Web UI to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic
Download
Technical parameters
LAN ports
Design
On the wall, Desktop, Rackmount
Switchning capacity [Gbps]
56
MAC address table
8000
Packet forwarding rate [Mpps]
41,6
Web management
Yes
Management
Web management, SSH, Telnet, Cloud (GDMS)
Features
VLAN, QoS, DHCP snooping, L2+
Power type
Mains power (230V)
Fans
No
LAN ports
24
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP cages
4
Optical interfaces
(4) 1000Mbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
24
PoE budget [W]
360
Serial port
RJ45
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
3,3
Width [mm]
440
Height [mm]
44
Depth [mm]
200
Default IP address
192.168.0.254
Default login and password
admin / (preset password, see label/engraving)
