Grandstream GWN7813P Layer 3 Managed Network PoE Switch, 24 ports / 4 SFP+

Grandstream GWN7813P Layer 3 Managed Network PoE Switch, 24 ports / 4 SFP+
Your price incl. VAT (20.0%)
2,003.99 RON
❌ The item is not available. There is no option to order.
Delivery No confirmed delivery date
Manufacturer
Product number
GWN7813P
Product Code
RL027.952
Warranty
36 months

Product description

The GWN7810 series are Layer 3 managed network switches that allow enterprises to build scalable, secure, and high-performance business networks that are fully manageable.

GWN7813P

Key features

  • 8/16/24 Gigabit Ethernet ports and 2/4 10Gigabit SFP+ ports
  • Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models, Ports 1-8 on the GWN7813P support PoE++
  • Supports deployment in IPv6 and IPv4 networks
  • ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
  • Embedded controller to manage switch; GWN Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform
  • Built-in QoS allows for prioritization of network traffic

Download

https://download.discomp.cz/Grandstream/Datasheets/Datasheet_GWN7811(P)_GWN7812P_GWN7813(P)_Series_English.pdf
Download Datasheet
https://download.discomp.cz/Grandstream/QIG/GWN7810_QIG_ML-2.pdf
Download Quick Start Guide

Technical parameters

LAN ports
Design
Rackmount, Desktop, On the wall
Switchning capacity [Gbps]
128
Packet forwarding rate [Mpps]
95,2
Web management
Yes
Management
Cloud (GDMS), SSH, Telnet, Web management
Features
DHCP snooping, L3, QoS, VLAN
Power type
Mains power (230V)
Fans
Yes
LAN ports
24
LAN speed
(24) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP+ cages
4
Optical interfaces
(4) 10Gbps
PoE-Out standards
802.3af, 802.3at, 802.3bt
Redundant power supply
Yes
PoE Out ports
24
PoE budget [W]
360
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
4,7
Width [mm]
440
Height [mm]
44
Depth [mm]
300
Default IP address
192.168.0.254
Default login and password
admin / (preset password, see label/engraving)
