RF elements Symmetrical Horn Sector antenna with TwistPort, 5GHz, 18dBi, 30°, Gen3

RF elements Symmetrical Horn Sector antenna with TwistPort, 5GHz, 18dBi, 30°, Gen3
Your price incl. VAT (20.0%)
672.83 RON
Comandat pentru disponibilitate
Delivery Data de livrare planificată prin curier către dvs 26-11-2025
RF elements
Manufacturer
RF elements
Product number
HG4-TP-S30
Product Code
RL030.185
Warranty
24 months

Having a question?
You have a choice of 2 variants
RF elements Asymmetrical Horn Antenna with TwistPort, 5GHz, 17dBi, 45°
HG4-TP-A45
622.95 RON excl. VAT
RF elements Symmetrical Horn Sector antenna with TwistPort, 5GHz, 18dBi, 30°, Gen3
HG4-TP-S30
560.69 RON excl. VAT
RF elements TP-ADAP-e2K TwistPort adaptor for ePMP2000 AP
RF elements TP-ADAP-e2K TwistPort adaptor for ePMP2000 APTP-ADAP-e2K
206.86 RON excl. VAT
Adaugă in coş
RF elements TP-ADAP-C5c TwistPort adaptor for Mimosa C5c
RF elements TP-ADAP-C5c TwistPort adaptor for Mimosa C5cTP-ADAP-C5c
61.53 RON excl. VAT
Adaugă in coş
RF elements TPA-RBC TwistPort aluminium adaptor for RouterBOARD
RF elements TPA-RBC TwistPort aluminium adaptor for RouterBOARDTPA-RBC
147.26 RON excl. VAT
Adaugă in coş
RF elements TPA-PAF TwistPort adaptor for Rocket Prism 5AC, airFiber 5X, LTU-Rocket and Wave MLO5
RF elements TPA-PAF TwistPort adaptor for Rocket Prism 5AC, airFiber 5X, LTU-Rocket and Wave MLO5TPA-PAF
248.18 RON excl. VAT
Adaugă in coş
RF elements TPA-SMA TwistPort adaptor with 2x RSMA connectors
RF elements TPA-SMA TwistPort adaptor with 2x RSMA connectorsTPA-SMA
75.82 RON excl. VAT
Adaugă in coş
RF elements TPA-R5ac TwistPort adaptor for Rocket AC Lite
RF elements TPA-R5ac TwistPort adaptor for Rocket AC LiteTPA-R5AC
124.63 RON excl. VAT
Adaugă in coş
RF elements TPA-RM5 TwistPort adaptor for Rocket M5
RF elements TPA-RM5 TwistPort adaptor for Rocket M5TPA-RM5
60.29 RON excl. VAT
Adaugă in coş
RF elements TPA-A5x TwistPort adaptor for Mimosa A5x
RF elements TPA-A5x TwistPort adaptor for Mimosa A5xTPA-A5x
61.53 RON excl. VAT
Adaugă in coş
RF elements TPA-AMU TwistPort adaptor for Mimosa B5x, C5x, C6x
RF elements TPA-AMU TwistPort adaptor for Mimosa B5x, C5x, C6xTPA-AMU
61.53 RON excl. VAT
Adaugă in coş
Antenna holder on mast L , lenght 35cm, height 20cm, d=42mm + 1x U-Bolt 100mm
Antenna holder on mast "L", lenght 35cm, height 20cm, d=42mm + 1x U-Bolt 100mmSL1-100-035-020-042
43.68 RON excl. VAT
Adaugă in coş

Download

https://download.discomp.cz/RFelements/Datasheets/HG4-TP-S30_Gen3.pdf
Download Datasheet

Technical parameters

LAN ports
Polarization
VH
F/B ratio [dB]
33
Designed for mast diameter [mm]
30 up to 80
Wind load [km/h]
180
Protection class
IP55
Wireless frequency
5 GHz
Elevation beam width (-6dB) [°]
30
Azimuth beam width (-6dB) [°]
30
Antenna type
Sector
RF connectors
TwistPort
Purpose
Outdoor
Antenna gain [dBi]
18
Material
Aluminum, Stainless steel, UV stabilized ABS plastic
Operating temperature [°C]
-30 up to 55
Weight [kg]
2,7
Width [mm]
240
Height [mm]
245
Depth [mm]
380
