Technical parameters
LAN ports
Switchning capacity [Gbps]
20
MAC address table
8000
Packet forwarding rate [Mpps]
14,9
Design
DIN rail, Industry
Jumbo frame [Bytes]
10000
Web management
Yes
Management
Web management
Features
VLAN
Power type
DC terminal
Fans
No
LAN ports
8
LAN speed
(8) 10/100/1000Mbps
Max. LAN ports speed
1G
SFP cages
2
Optical interfaces
(2) 1000Mbps
Max. power consumption [W]
6
Chassis design
Metal
Power via connector/terminal
7 .. 57V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 70
Height [mm]
44
Depth [mm]
122
Width [mm]
132
Default IP address
192.168.1.2
Default login and password
admin / (preset password, see label/engraving)
