Ubiquiti AirFiber AF-24HD, 2Gbps+ Backhaul, 24GHz (price per piece)

Ubiquiti AirFiber AF-24HD, 2Gbps+ Backhaul, 24GHz (price per piece)
Your price incl. VAT (20.0%)
15,640.84 RON
✅ In Stock < 10 Бр.
Delivery Planned Delivery Date by Courier to you 04-12-2024
Ubiquiti Networks
Manufacturer
Product number
AF-24HD
Product Code
RL002.589
Warranty
24 months

Product description

Featuring the world’s best unlicensed-band spectral efficiency at 15.9 bps/Hz, the airFiber®24 HD supports the dense modulation rates, up to 256QAM, that are required for high data rates, up to 2 Gbps.

AF-24HD

2 independent antennas

airFiber features a dual-independent, 2x2 MIMO, high-gain reflector antenna system. Separate yet integrated transmit ( TX) and receive (RX) antennas help extend link budgets by eliminating the extra RF losses caused by the switches or duplexers required in systems with common TX/RX antennas.

AF-24HD

FDD and HDD

Conventional wireless standards impose a latency by having to receive a packet before a packet is transmitted. airFiber can transmit data synchronously without any wait time. airFiber features traditional TDD and FDD modes of operation in addition to the proprietary Hybrid Division Duplexing (HDD) mode, which provides a breakthrough in range and spectral efficiency performance.

Based on the ranging algorithm built into the air protocol, the airFiber radios use patent-pending HDD technology to calculate the propagation delay and know when each radio can transmit and receive, so they send packets in precise synchronization. Packet transmission latency is virtually eliminated.

AF-24HD

2 Ethernet ports

For seamless monitoring and settings is used in the unit 2 Ethernet ports, one of whom is designed only for management 2nd one for data and management.

Package contains

  • Device
  • PoE power adapter
  • Power cord
  • Holder

Download

https://download.discomp.cz/Ubiquiti/CE/AirFiber24_DoC.pdf
Download CE
https://download.discomp.cz/Ubiquiti/Datasheets/airFiber_DS.pdf
Download Datasheet
https://download.discomp.cz/Ubiquiti/QSG/airFiber_AF-24HD_QSG.pdf
Download Quick Start Guide
https://www.ubnt.com/download/airfiber
Download Latest Firmware

Technical parameters

LAN ports
Power over Ethernet
42 .. 58V DC
Polarization
VH
Sensitivity [dBm]
-87
F/B ratio [dB]
70
Designed for mast diameter [mm]
30 up to 100
Cross-Pol Isolation [dB]
28
Wind load [km/h]
200
Radom
Yes
Frequency range [MHz]
24050 - 24250
Maximum modulation
256 QAM
Channel bandwidth [MHz]
100
Transmission speed - 24GHz [Mb/s]
1024
Tx power 24GHz [dBm]
33 (FCC/IC), 20 (CE) - EIRP
Security
WPA2 AES
Elevation beam width (-6dB) [°]
3,5
Azimuth beam width (-6dB) [°]
3,5
Antenna gain [dBi]
Tx = 33, Rx = 40
Operating system
airOS F
LAN ports
2
LAN speed
(1) 10/100/1000Mbps + (1) 10/100Mbps (managment)
Max. power consumption [W]
50
Operating temperature [°C]
-40 up to 55
Weight [g]
17300
Width [mm]
593
Height [mm]
768
Depth [mm]
370
Default IP address
192.168.1.20
Default login and password
ubnt / ubnt
GPS modul
Yes
Other features
RJ-12 - Alignment Tone Port
