TP-Link VIGI NVR1008H-8P - NVR, 8 channels, 8x PoE

Product description

Recording device from the TP-Link brand for recording and powering up to 8 IP cameras. It can record camera recordings in a maximum resolution of up to 8 MP. The device can be connected to the network with one 10/100 Mbps LAN port and the other 8x 10/100 Mbps LANs have 802.3af/at PoE support with total PoE budget 53W. The connectors include 2 USB ports for connecting a keyboard and mouse, audio input/output, 4K HDMI and a VGA connector. The maximum consumption of the recorder itself without HDD and connected cameras is 2.4 W.

Key features

• 8 channels with 8MP resolution
• 1× Sata (up to 10 TB)
• 9× 10/100Mbps LAN - 8× PoE (802.3af/at), PoE budget 53W
• 2x USB 2.0
• 1x 4K HDMI (3840 × 2160px) + 1x VGA
• Codec support: H.265+/H.265/ H.264+/H.264
• Wide camera support thanks to Onvif compatibility
• Remote management and monitoring thanks to the VIGI application for iOS and Android
• Two-way audio - With voice intercom support, have a two-way conversation and monitor your image from anywhere.
• Possibility of installation in a rack, when purchasing a rackmount attachment

Package contents

• Device
• Power adapter 53.5 V/1.31 A
• Mouse
• Screws for fixing the HDD

Download

https://download.discomp.cz/TP-LINK/Datasheets/NVR1008H-8P(UN)1.20%20Datasheet.pdf

Datasheet

https://download.discomp.cz/TP-LINK/QSG/NVR1008H_EU2_IG.pdf

Quick Start Guide

https://download.discomp.cz/TP-LINK/Userguides/NVR1008H_UserGuide.pdf

User Guide
