Teltonika TRB143 M-BUS Gateway
Your price incl. VAT (20.0%)
887.28 RON
✅ In Stock < 10 Бр.
Planned Delivery Date by Courier to you 10-12-2025
Product description
The TRB143 industrial gateway was designed with an integrated M-Bus interface specifically for telemetry and utility-monitoring applications. It features cellular and wired connectivity, one Gigabit Ethernet port, and a pair of digital Inputs/Outputs, making it applicable to a variety of environment-monitoring scenarios.
Key features
- M-BUS INTERFACE: Supporting up to 250 client devices
- CONNECTIVITY: 4G/LTE (Cat 4), 3G, 2G
- DURABILITY: Rugged aluminum housing
- COMPACT: Simple integration
Package contents
- Device
- 18 W PSU
- Mobile antenna (magnetic mount, SMA male, 3 m cable)
- Hex key
- LAN cable
- QSG (Quick Start Guide)
Download
Technical parameters
LAN ports
Power over Ethernet
12 .. 30V DC
Protection class
IP30
Design
Desktop
Operating mode
Cellular router
Management
SSH, Teltonika RMS, Web management
Wireless frequency
2G (GSM), 3G (GSM), 4G (GSM), LTE
Type of antenna
Detachable
Detachable antennas
1
RF connectors
(1) SMA female
Purpose
Indoor
Integrated 4G/LTE radio part
Yes
Power type
4-pin automotive
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
PoE type
PoE-In (only)
Max. power consumption [W]
6
Power via connector/terminal
12 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
145
Width [mm]
75
Height [mm]
25
Depth [mm]
73
CPU
ARM Cortex A7
CPU frequency [MHz]
1300
SIM slot
Yes
SIM slots quantity
1
IPv6 support
Yes
Internal storage [MB]
512
Default IP address
192.168.2.1
RAM [MB]
256
Default login and password
admin / (preset password, see label/engraving)
