WAN Ports

1

WAN speed

(1) 10/100Mbps

Wireless frequency

2.4 GHz, 2G (GSM), 3G (GSM), 4G (GSM), LTE

WiFi standards

802.11n, 802.11b/g

Transmission speed - 2.4GHz [Mb/s]

300

RF connectors

(2) RSMA female, (2) SMA female

4G/LTE bands support

(1) 2100 MHz, (20) 800 MHz, (3) 1800 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz

Operating system

RutOS (OpenWrt based Linux OS)

LAN ports

3

LAN speed

(3) 10/100Mbps

Max. power consumption [W]

7

Buttons

Reset

Operating temperature [°C]

-40 up to 75

Weight [g]

287

Width [mm]

110

Height [mm]

50

Depth [mm]

100

CPU frequency [MHz]

580

SIM slot

Yes

SIM slots quantity

2

RAM [MB]

128
