RF elements STH-30-USMA Symmetrical antenna StarterHorn, 30°, USMA, 5GHz, 18dBi

Your price incl. VAT (20.0%)

483.22 RON

✅ In Stock 90+ Бр.

Planned Delivery Date by Courier to you 04-12-2024

Add to Cart

Manufacturer

RF elements

Product number

STH-30-USMA

Product Code

RL009.500

Warranty

24 months

Having a question?

• Related products

Pigtail Flexi 0,5m - N male / RSMA maleFL-RM-NM-005

33.28 RON excl. VAT

Pigtail Flexi 0,25m - RSMA male / RSMA maleFL-RM-RM-0025

28.20 RON excl. VAT

Ubiquiti IS-5AC - 5 GHz IsoStation AC, airMAX AC, 45°IS-5AC

515.97 RON excl. VAT

Ubiquiti PS-5AC - airMax AC PrismStation, 5GHz Radio-only, shielded and features airPrism Active RF FilterPS-5AC

1205.63 RON excl. VAT

•
• Download
• Video

Download

https://download.discomp.cz/rfelements/datasheets/Datasheet-STH-30-USMA.pdf

Datasheet

Technical parameters

LAN ports

MIMO, SISO

2 x 2

Polarization

VH

Designed for mast diameter [mm]

20 up to 55

Wind load [km/h]

160

Protection class

IP55

Wireless frequency

5 GHz

Elevation beam width (-6dB) [°]

30

Azimuth beam width (-6dB) [°]

30

Antenna type

Sector

RF connectors

(2) RSMA female, IsoStation port

Purpose

Outdoor

Antenna gain [dBi]

18

Material

UV stabilized ABS plastic, Aluminum, Stainless steel

Operating temperature [°C]

-30 up to 55

Weight [kg]

1,3

Width [mm]

214

Height [mm]

214

Depth [mm]

301
