Grandstream GWN7803PH Pro, Gigabit PoE switch

Grandstream GWN7803PH Pro, Gigabit PoE switch
Your price incl. VAT (20.0%)
1,807.34 RON
❌ The item is not available. There is no option to order.
Delivery No confirmed delivery date
Manufacturer
Grandstream
Product number
GWN7803PH Pro
Product Code
RL030.845
Warranty
36 months

Having a question?
You have a choice of 7 variants
Grandstream GWN7801P Pro, Gigabit PoE switch
GWN7801P Pro
647.75 RON excl. VAT
Grandstream GWN7802P Pro, Gigabit PoE switch
GWN7802P Pro
1,126.90 RON excl. VAT
Grandstream GWN7803PL Pro, Gigabit PoE switch
GWN7803PL Pro
1,257.79 RON excl. VAT
Grandstream GWN7806PL Pro, Gigabit PoE switch
GWN7806PL Pro
2,390.95 RON excl. VAT
Grandstream GWN7806PH Pro, Gigabit PoE switch
GWN7806PH Pro
3,143.76 RON excl. VAT
Grandstream GWN7803 Pro, Gigabit switch
GWN7803 Pro
868.47 RON excl. VAT
Grandstream GWN7803PH Pro, Gigabit PoE switch
GWN7803PH Pro
1,506.12 RON excl. VAT
Gembird Power cord 230V, 1,8m, angled
Gembird Power cord 230V, 1,8m, angledPC-186A-VDE
20.51 RON excl. VAT
Add to Cart
MaxLink 10G SFP+ optical module, MM, 850nm, 300m, 2x LC connector, DDM
MaxLink 10G SFP+ optical module, MM, 850nm, 300m, 2x LC connector, DDMML-S+85D-03
31.50 RON excl. VAT
Add to Cart
Masterlan patch cable UTP, Cat5e, 1m, yellow
Masterlan patch cable UTP, Cat5e, 1m, yellowPCU5E-1YW-MS
1.77 RON excl. VAT
Add to Cart
MaxLink 10G SFP+ optical module, SM, 1310nm, 10km, 2x LC connector, DDM
MaxLink 10G SFP+ optical module, SM, 1310nm, 10km, 2x LC connector, DDMML-S+31D-10
52.50 RON excl. VAT
Add to Cart
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDM
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
68.28 RON excl. VAT
Add to Cart
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDM
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
68.28 RON excl. VAT
Add to Cart
Masterlan comfort patch cable UTP, Cat5e, 5m, gray
Masterlan comfort patch cable UTP, Cat5e, 5m, grayPCU5E-5-MSC
12.47 RON excl. VAT
Add to Cart

Product description

The Grandstream GWN7803PH Pro is a managed L2+ switch with a switching capacity of 88Gbps, offering (24) 1G PoE++ ports, a PoE budget of 400W, (2) SFP+ slots and support for management via local web interface, GDMS cloud management and GWN Manager.

Grandstream GWN7803PH Pro Banner

Key features

  • (24) 1Gbps PoE++ ports, (2) SFP+ slots and (1) RJ45 console port
  • 802.3af/at/bt PoE++ with up to 60W/port and a total budget of up to 400W
  • Convenient and intelligent management via the web user interface and the cloud
  • Supports redundant power via an external RPS
  • VLAN, QoS, ARP Inspection, IP Source Guard, DoS protection, port security and DHCP snooping

Package contents

  • Device
  • Rack mounting kit
  • Power cable

Download

https://download.discomp.cz/Grandstream/Datasheets/Datasheet_GWN7800_Pro_Series_English.pdf
Download Datasheet
https://download.discomp.cz/Grandstream/QIG/GWN780x-Pro-250724-01.pdf
Download Quick Install Guide

Technical parameters

LAN ports
Jumbo frame [Bytes]
12000
Design
Rackmount
Packet forwarding rate [Mpps]
65,48
Switchning capacity [Gbps]
88
MAC address table
16000
Web management
Yes
Management
Cloud (GDMS), Web management, SSH, Telnet
Features
L2+, VLAN, QoS, DHCP snooping
Power type
Mains power (230V)
Fans
Yes
LAN speed
(24) 10/100/1000Mbps
Management LAN
Yes
PoE type
PoE-Out (only)
RJ45 ports 1G
24
SFP+ cages
2
Optical interfaces
(2) 10Gbps
PoE-Out standards
802.3af, 802.3at, 802.3bt
PoE Out ports
24
Redundant power supply
Yes
PoE budget [W]
400
Max. power consumption [W]
471
Serial port
RJ45
Chassis design
Metal
Buttons
Reset
Operating temperature [°C]
0 up to 45
Depth [mm]
300
Width [mm]
440
Height [mm]
44
Default IP address
192.168.0.254, Dynamic from DHCP
Default login and password
admin / (preset password, see label/engraving)
