MERCUSYS MA49BE, Wi-Fi 7 and Bluetooth PCIe adapter
Your price incl. VAT (20.0%)
254.86 RON
Ordered for stock
No confirmed delivery date
Product description
The MERCUSYS MA49BE is a tri-band Wi-Fi 7 PCIe adapter that provides your computer with very fast and stable Wi-Fi connectivity with throughput up to 9.34Gbps. In addition, it features Bluetooth 5.4 technology for connecting peripherals such as headphones, keyboards and controllers.
Supports only Intel® processors!
Key features
- Total throughput up to 9.34Gbps - 688Mbps on 2.4GHz (2x2), 2882Mbps on 5GHz (2x2) and 5765Mbps on 6GHz (2x2)
- MU-MIMO and OFDMA - more efficient operation and simultaneous connectivity for multiple devices
- Multi-Link Operation (MLO) - send and receive data simultaneously across different bands to increase throughput and reduce latency
- Enhanced WPA3 security - the latest and most advanced Wi-Fi protection standard
- Bluetooth 5.4 - improved speed, range, security and reliability over the previous generation
- Flexible Installation - includes both standard and low-profile brackets for compatibility with various board designs
- Broader Coverage - two high-performance omnidirectional antennas ensure stronger signal transmissions and reception
- Compatible with Windows 11/10
Package contents
- Device
- Quick Installation Guide
Download
Technical parameters
LAN ports
Type of network card
WLAN
Interface
PCI Express
Sensitivity [dBm]
-95
Size
Low profile, Full profile
Wireless frequency
Bluetooth, 2.4 + 5 + 6 GHz (triple band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax, 802.11be
Transmission speed - 5GHz [Mb/s]
2880
Transmission speed - 2.4GHz [Mb/s]
688
Transmission speed - 6GHz [Mb/s]
5760
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2
6GHz MIMO
2 x 2
Type of antenna
Detachable
Operating temperature [°C]
0 up to 40
Width [mm]
121
Height [mm]
22
Depth [mm]
80
