Ubiquiti UniFi AP U7 In-Wall

Power over Ethernet

802.3af, 802.3at, 42 .. 57V DC

Operating mode

Access Point

Wireless frequency

2.4 + 5 GHz (dual band)

WiFi standards

802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax, 802.11be

MU-MIMO

Yes

Transmission speed - 5GHz [Mb/s]

4300

Transmission speed - 2.4GHz [Mb/s]

688

Tx power 2.4GHz [dBm]

23

Tx power 5GHz [dBm]

24

Security

WPA, WPA2, WPA3

2.4GHz MIMO

2 x 2

5GHz MIMO

2 x 2

Type of antenna

Built-in

Purpose

Indoor

Roaming

Yes

Antenna gain [dBi]

4, 8

LAN ports

3

LAN speed

(3) 100/1000/2500Mbps

Gigabit LAN

Yes

PoE type

PoE-Out + PoE-In

PoE Out ports

1

Max. power consumption [W]

13

Buttons

Reset

Operating temperature [°C]

-30 up to 40

Weight [g]

400

Width [mm]

99

Height [mm]

137

Depth [mm]

30
