Grandstream GWN7806P Layer 2+ Managed Network PoE Switch, 48 ports / 6 SFP+
Your price incl. VAT (20.0%)
2,677.34 RON
✅ Availability in an external Partner
Planned Delivery Date by Courier to you 27-11-2024
3409.00 RON excl. VAT
31.06 RON excl. VAT
49.00 RON excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1270/Rx1330nm, 10km, 1x LC connector, DDMML-S+2733-10
65.42 RON excl. VAT
MaxLink 10G SFP+ optical module, WDM(BiDi), SM, Tx 1330/Rx1270nm, 10KM, 1x LC connector, DDMML-S+3327-10
65.42 RON excl. VAT
Product description
The GWN7806(P) is a high-performance layer 2+ managed network switch with 48 ports that allows small-to-medium enterprises to build scalable, secure, and smart business networks that are fully manageable.
Key features
- 48 Gigabit Ethernet ports and 6 Gigabit SFP+ ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
- Supports deployment in IPv6 and IPv4 networks
- Reliability features including fault detection, device protection, dual boot, dual system file redundancy, link aggregation, storm control and more
- ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
- Embedded controller to manage switch; GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform
- Built-in QoS allows for prioritization of network traffic
- Supports stacking (pending) for easy management of up to 16 switches in one interface while creating redundant backup between multiple devices
Download
Technical parameters
LAN ports
Design
Desktop, Rackmount
Switchning capacity [Gbps]
216
Packet forwarding rate [Mpps]
160,7
Web management
Yes
Management
Web management, SSH, Telnet, Cloud (GDMS)
Features
VLAN, QoS, DHCP snooping, L2+
Power type
Mains power (230V)
Fans
Yes
LAN ports
48
LAN speed
(48) 10/100/1000Mbps
Max. LAN ports speed
1G
PoE type
PoE-Out (only)
SFP+ cages
6
Optical interfaces
(6) 10Gbps
PoE-Out standards
802.3af, 802.3at
PoE Out ports
48
PoE budget [W]
400
Chassis design
Metal
Power via connector/terminal
100-240 V AC~50/60 Hz
Buttons
Reset
Operating temperature [°C]
0 up to 45
Weight [kg]
5,1
Width [mm]
440
Height [mm]
44
Depth [mm]
301
Default login and password
admin / (preset password, see label/engraving)
