Huawei AP661 - WiFi6 indoor Tripple Band AP, smart antenna, USB. BLE

Huawei AP661 - WiFi6 indoor Tripple Band AP, smart antenna, USB. BLE
Your price incl. VAT (20.0%)
835.99 RON
❌ The item is not available. There is no option to order.
Delivery No confirmed delivery date
Manufacturer
Product number
AP661
Product Code
RL027.622
Warranty
36 months

Product description

Step into the era of revolutionary Wi-Fi performance with the Huawei eKitEngine AP661. This indoor access point complies with the Wi-Fi 6 (802.11ax) standard and delivers not only speeds of up to 6.575 Gbps but also intelligent features for signal optimization and coverage. Thanks to the built-in smart antennas, the signal automatically adapts to the environment, ensuring stable and reliable coverage regardless of user movement using Beamforming technology. This makes it an ideal choice for high-density user environments such as offices, schools, or stadiums.

The AP661 supports 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO and 4x4 MIMO) bands, allowing efficient utilization of the radio spectrum. The Wi-Fi 6 (802.11ax) standard brings increased capacity and bandwidth, reducing latency and improving user experience.

Key Features:

  • MU-MIMO: Data transmission between AP and multiple STAs simultaneously, increasing radio spectrum utilization.
  • OFDMA: Latency reduction and network efficiency improvement.
  • Spatial Multiplexing: Minimization of interference and increase in network capacity.
  • Target Wake Time (TWT) technology: Extends battery life of connected devices.
  • SmartRadio: Optimizes air interface, balances load, and identifies interference.

The Huawei eKitEngine AP661 offers not only performance but also network security and management. It analyzes non-Wi-Fi sources of interference and monitors connected devices to ensure network security and connection reliability. We provide comprehensive solutions for modern enterprises that require powerful, reliable, and secure Wi-Fi connectivity.

Additional Features:

  • Cloud Management: Easy management and integration into your network.
  • IoT Expansion: Possibility to connect ZigBee and RFID devices.
  • Operating Modes: Flexibility to choose between Fit, Fat, and cloud management.
  • 10/100/1000Mbps + 10/100/1000/2500Mbps Ethernet ports: For fast and reliable network connectivity.
  • POE 802.3at Power Option: Easy installation and cable minimization.

Package Contents:

  • Device

Download

https://download.discomp.cz/Huawei/Datasheets/AP661.pdf
Download Datasheet

Technical parameters

LAN ports
Frequency range [MHz]
5180 - 5825, 2412 - 2472
Power over Ethernet
802.3at
Operating mode
Access Point
Wireless frequency
2.4 + 5 + 5 GHz (triple band)
WiFi standards
802.11a, 802.11ac, 802.11ac - wave2, 802.11ax, 802.11b/g, 802.11n
MU-MIMO
Yes
Transmission speed - 2.4GHz [Mb/s]
574
Transmission speed - 5GHz [Mb/s]
6000
Tx power 2.4GHz [dBm]
21
Tx power 5GHz [dBm]
18
Security
WEP, WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
2 x 2, 4 x 4
Type of antenna
Built-in
Internal antennas
8
Purpose
Indoor
Antenna gain [dBi]
5, 4
LAN ports
2
LAN speed
(1) 100/1000/2500Mbps + (1) 10/100/1000Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
21
USB ports 2.0
1
Power via connector/terminal
12V DC
Buttons
Reset
Operating temperature [°C]
-10 up to 50
Weight [g]
1080
Depth [mm]
220
Width [mm]
220
Height [mm]
50
USB
Yes
