Ubiquiti UniFi AP U7-Pro-Wall

Ubiquiti UniFi AP U7-Pro-Wall
Your price incl. VAT (20.0%)
1,067.12 RON
Ordered for stock
Delivery No confirmed delivery date
Ubiquiti
Manufacturer
Product number
U7-Pro-Wall
Product Code
RL027.569
Warranty
24 months

Product description

Ubiquiti U7 Pro Wall is a highly powerful triple-band unit supporting Wi-Fi 7. It operates in the 2.4 GHz band at a speed of 688 Mb/s, in the 5 GHz band at a speed of 4.3 Gb/s, and in the 6 GHz band, even 5.7 Gb/s. Thanks to the triple band, the unit ensures excellent connectivity and extensive coverage. For network connection, a LAN port with a speed of up to 2.5 Gb/s is available. The access point is powered via PoE+.

Centralized Unit Management

To manage the device, it is necessary to download the original software called UniFi Network Controller from the official website, which allows managing the entire network. An undeniable advantage of the UniFi Controller is that it is completely free without any limitations! This centralized management allows uploading maps and setting both basic parameters and advanced functions, such as SSID, guest account, splash page, traffic statistics, and a list and status of associated clients, easily and quickly.

U6-LR

Package Contents

  • Device
  • Wall mounts
  • Drilling template
  • Cable tie
  • Mounting kit

Download

https://dl.ui.com/qig/u7-pro-wall/#index
Download Quick Install
https://techspecs.ui.com/unifi/wifi/u7-pro-wall#datasheet
Download Datasheet

Technical parameters

LAN ports
Power over Ethernet
802.3at
Operating mode
Access Point
Wireless frequency
2.4 + 5 + 6 GHz (triple band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax, 802.11be
MU-MIMO
Yes
Transmission speed - 5GHz [Mb/s]
8640
Transmission speed - 2.4GHz [Mb/s]
688
Transmission speed - 6GHz [Mb/s]
5760
Tx power 2.4GHz [dBm]
23
Tx power 5GHz [dBm]
29
Tx power 6GHz [dBm]
23
Security
WPA, WPA2, WPA3
2.4GHz MIMO
2 x 2
5GHz MIMO
4 x 4
6GHz MIMO
2 x 2
Type of antenna
Built-in
Purpose
Indoor
Roaming
Yes
Antenna gain [dBi]
6, 4
LAN ports
1
LAN speed
(1) 100/1000/2500Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
22
Buttons
Reset
Operating temperature [°C]
-30 up to 60
Weight [g]
680
Width [mm]
206
Height [mm]
46
Depth [mm]
206
IPv6 support
Transparent (bridge mode)
Default IP address
Dynamic from DHCP
