Ubiquiti UniFi AP U7-Pro-Max

Ubiquiti UniFi AP U7-Pro-MaxBestseller
Your price incl. VAT (20.0%)
1,480.66 RON
Ordered for stock
Delivery Planned Delivery Date by Courier to you 19-03-2025
Ubiquiti
Manufacturer
Product number
U7-Pro-Max
Product Code
RL027.568
Warranty
24 months

Product description

Ubiquiti U7 Pro Max is the most powerful unit in the U7 series, naturally supporting Wi-Fi 7. It operates in the 2.4 GHz band at a speed of 688 Mb/s, in the 5 GHz band at an incredible speed of 8.6 Gb/s, and in the 6 GHz band at 5.7 Gb/s. Thanks to the triple band, the unit ensures excellent connectivity and wide coverage. For network connection, a LAN port with a speed of up to 2.5 Gb/s is available. The access point is powered via PoE+.

Centralized Unit Management

To manage the device, it is necessary to download the original software called UniFi Network Controller from the official website, which allows you to control the entire network. The undeniable advantage of the UniFi Controller is that it is completely free without any restrictions! This centralized management allows uploading maps and setting basic parameters as well as advanced features, such as SSID, guest account, welcome page, traffic statistics, and a list and status of associated clients, always easily and quickly.

U6-LR

Package Contents

  • Device
  • Wall mounts
  • Drilling template
  • Cable tie
  • Mounting kit

Download

https://dl.ui.com/qig/u7-pro-max/#index
Download Quick Install
https://techspecs.ui.com/unifi/wifi/u7-pro-max#datasheet
Download Datasheet

Technical parameters

LAN ports
Power over Ethernet
Yes, 44 .. 57V DC
Operating mode
Access Point
Wireless frequency
2.4 + 5 + 6 GHz (triple band)
WiFi standards
802.11n, 802.11a, 802.11ac, 802.11b/g, 802.11ax, 802.11be
MU-MIMO
Yes
Transmission speed - 6GHz [Mb/s]
5700
Transmission speed - 5GHz [Mb/s]
8600
Transmission speed - 2.4GHz [Mb/s]
688
Tx power 2.4GHz [dBm]
23
Tx power 5GHz [dBm]
29
Tx power 6GHz [dBm]
23
Security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
2.4GHz MIMO
2 x 2
5GHz MIMO
4 x 4
6GHz MIMO
2 x 2
Type of antenna
Built-in
Purpose
Indoor
Antenna gain [dBi]
6, 4, 5.8
LAN ports
1
LAN speed
(1) 100/1000/2500Mbps
Gigabit LAN
Yes
PoE type
PoE-In (only)
Max. power consumption [W]
25
Buttons
Reset
Operating temperature [°C]
-30 up to 60
Weight [g]
680
Height [mm]
46
Width [mm]
206
Depth [mm]
206
IPv6 support
Transparent (bridge mode)
Default login and password
ubnt / ubnt
