Solarix ethernet cable CAT6 UTP PE outdoor, 500m reel

Solarix ethernet cable CAT6 UTP PE outdoor, 500m reel
Your price incl. VAT (20.0%)
1,295.78 RON
✅ Availability in an external Partner
Delivery Planned Delivery Date by Courier to you 11-12-2024
Solarix
Manufacturer
Product number
SXKD-6-UTP-PE
Product Code
RL001.933
Warranty
36 months

Product description

The installation cable from product line Solarix-Category 6 labeled SXKD-6-UTP-PE is an outdoor unshielded cable with polyethylene shell that is designed for harsh installations where a standard data cable with PVC or LSOH jacket does not provide sufficient protection against environmental influences. The cable easily meets and also exceeds the requirements specified in the international standards ANSI/TIA/EIA 568, ISO/IEC 11801 and EN 50173, including all the latest additions to Category 6. Solarix-category 6E are designed for horizontal distribution and are available in shielded and unshielded versions with different types of shells - ie. PVC, LSOH or UV stable PE. The conductors of these cables are made of high quality copper wire size AWG 23. The individual pairs are separated by a plastic cross. Like other cables, also cable SXKD-6-UTP-PE is labeled each one meter in the range of 0-500 m. The cable is supplied on spool, which contains all the necessary product information, including barcodes, production batch, description and main technical parameters (eg. NVP in the form of a QR code).

Vlastnosti kabelu Solarix Cat6

Download

https://download.discomp.cz/solarix/datasheets/SXKD-6-UTP-PE.pdf
Download Datasheet

Technical parameters

LAN ports
Category
CAT6
Shielding type
UTP (U/UTP)
Bandwidth [MHz]
250
Installation temperature [°C]
0 up to 50
Storage temperature [°C]
-20 up to 70
Weight [kg/km]
42
Ethernet support
1000 Base-T, 1000 Base-TX
Conductor wire gauge
AWG23
Cable type
Solid
CPR class
Fca
Purpose
Outdoor
Conductor material
Copper
Sheath material
PE
Length [m]
500
Outer diameter [mm)
6,3
Operating temperature [°C]
-20 up to 70
Color
Black
