Raspberry Pi 3B+ UniFi Controller, rackmount

Raspberry Pi 3B+ UniFi Controller, rackmount
Your price incl. VAT (20.0%)
445.66 RON
✅ In Stock < 10 Бр.
Delivery Planned Delivery Date by Courier to you 04-12-2024
Manufacturer
Product number
RPI303-CK-RM
Product Code
RL018.297
Warranty
24 months

Product description

Raspberry Pi 3B + UniFi Controller is a compact device with pre-installed UniFi Controller with the possibility of remote management of all Unifi AP units based on the very high-quality HW platform Raspberry Pi 3B+ with enough power to manage up to 40 devices (UniFi AP, UniFi Switch, USG), which is almost 2× the power compared to the standard UC-CK device from Ubiquiti Networks. Thanks to this device, you no longer have to install UniFi Controller on desktop PCs or servers with much higher power consumption.

Key Features

  • Pre-installed UniFi Controller - performance to manage UP to 40 DEVICES
  • 1.4 GHz 64-bit quad-core ARM Cortex-A53 CPU, 1 GB RAM
  • 4× USB 2.0 ports
  • MicroSDHC slot
  • Gigabit Ethernet port
  • Maximum power consumption 7 W - power supply via microUSB (5 V/ 2.5 A)
  • Quiet operation without a fan
  • Compatibility with existing accessories - dimensions and layout of Pi 3B+ connectors are identical to the previous Pi 3B / 2B / 1B+

Easy installation

Installation of Raspberry Pi 3B+ UniFi Controller (so-called raspberries) is very simple - just connect to the network with an Ethernet cable, connect the power supply, wait for booting (takes about 2 minutes) and using a web browser, simply enter the IP address that your raspberry received from the dhcp server, or the fallback address 192.168.1.30.

Raspberry Pi 3B+ UniFi Controller

Package Contents

  • Device - Raspberry Pi 3B+
  • MicroSD card with pre-installed UniFi Controller
  • Rackmount case

Download

https://download.discomp.cz/oem/UniFi_RPi_manual_AJ.pdf
Download Manual [EN]
https://download.discomp.cz/oem/UniFi_RPi_manual_CZ.pdf
Download Manual [CZ]
https://download.discomp.cz/Raspberry/Datasheets/raspberry-pi-3-b-plus-product-brief.pdf
Download Datasheet

Technical parameters

LAN ports
Design
Desktop, Rackmount
Pre-installed controller
UniFi Network
Power type
USB (5V)
Fans
No
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Max. power consumption [W]
7
USB ports 2.0
4
Power via connector/terminal
5V / 2,5A
Operating temperature [°C]
0 up to 50
Width [mm]
82
Height [mm]
44
Depth [mm]
91
Color
Black
CPU
ARM Cortex-A53
CPU frequency [MHz]
1400
CPU cores
4
USB
Yes
Default IP address
Dynamic from DHCP, 192.168.1.30
RAM [MB]
1024
Default login and password
Is set by the user at the first startup
