Design

Rackmount, Desktop

Switchning capacity [Gbps]

20

MAC address table

8000

Jumbo frame [Bytes]

10000

Packet forwarding rate [Mpps]

14,9

Web management

Yes

Management

Web management, SSH, Telnet, Wi-Tek Cloud, Mobilní aplikace

Features

VLAN, QoS, DHCP snooping, L2+

Power type

Mains power (230V)

Fans

No

LAN ports

8

LAN speed

(8) 10/100/1000Mbps

Max. LAN ports speed

1G

PoE type

PoE-Out (only)

SFP cages

2

Optical interfaces

(2) 1000Mbps

PoE-Out standards

802.3at, 802.3af

PoE Out ports

8

PoE budget [W]

140

Max. power consumption [W]

154

Serial port

RJ45

Buttons

Reset

Operating temperature [°C]

-10 up to 50

Weight [g]

1720

Width [mm]

280

Height [mm]

44

Depth [mm]

180

Default IP address

192.168.0.1

Default login and password

admin / admin
