Multiple WAN

Yes

Concurrent Session

1000000

Supported VPN

Identity Endpoint One-Click, IPSec, L2TP, OpenVPN, Site Magic, Teleport Zero-Configuration, WireGuard

IPsec VPN Throughput [Mb/s]

580

Design

Rackmount

WAN speed

(1) 2.5GE + (1) SFP28

Management

UniFi Network

Power type

Mains power (230V)

Fans

Yes

LAN ports

4

LAN speed

(1) 2.5GE + (2) SFP+ + (1) SFP28

Gigabit LAN

Yes

SFP+ cages

2

SFP28 cages

2

Optical interfaces

(2) 10Gbps + (2) 25Gbps

Redundant power supply

Yes

Max. power consumption [W]

82

Chassis design

Metal

Power via connector/terminal

230V AC

Buttons

Reset

Operating temperature [°C]

0 up to 40

Depth [mm]

325

Width [mm]

442

Height [mm]

44

CPU frequency [MHz]

2000

IPv6 support

Yes

Default IP address

192.168.1.1

RAM [MB]

16384

Default login and password

Is set by the user at the first startup

Other features

Touchscreen
