Teltonika TRB160 4G LTE IoT Gateway

Teltonika TRB160 4G LTE IoT Gateway
Вашата цена с ДДС (20.0%)
807.12 RON
✅ В наличност < 10 Бр.
Delivery Планирана Дата Доставка на Куриер до Вас 01-01-2025
Teltonika
Производител
Продуктов номер
TRB160100000
Продуктов Код
RL027.771
Гаранция
24 месеца

Описание на продукт

Това е автоматичен превод. Оригиналния текст може да видите тук

The TRB160 is an ultra-small, lightweight, and energy-efficient IoT gateway equipped with mission-critical LTE Cat 6, Gigabit Ethernet, and a virtual network interface via USB Type-C for simultaneous powering and network data provision. This IoT gateway can reach cellular speeds of up to 300 Mbps with carrier aggregation in a broad range of applications and supports a wide range of industrial-grade protocols for M2M communication.

Teltonika TRB160 Teltonika TRB160

Package contents

  • Device
  • 9 W PSU
  • (2) Mobile antenna (magnetic mount, SMA male, 3 m cable)
  • USB Type-C cable (0.8 m)
  • hex key
  • Ethernet cable
  • QSG (Quick Start Guide)
  • Packaging box

Свали

https://download.discomp.cz/Teltonika/Datasheets/trb160-datasheet-2024-v13.pdf
Свали Datasheet
https://wiki.teltonika-networks.com/view/QSG_TRB160
Свали Link to Quick Start Guide
https://wiki.teltonika-networks.com/view/TRB160_Manual
Свали Link to User Manual

Технически параметри

LAN ports
Wireless frequency
3G (GSM), 4G (GSM), LTE
RF connectors
(2) SMA male
Power type
DC connector
Operating system
RutOS (OpenWrt based Linux OS)
LAN ports
1
LAN speed
(1) 10/100/1000Mbps
Max. power consumption [W]
3,3
Power via connector/terminal
9 .. 30V DC
Buttons
Reset
Operating temperature [°C]
-40 up to 75
Weight [g]
172
Depth [mm]
74
Width [mm]
83
Height [mm]
25
CPU
Qualcomm, 1.2 Ghz, ARM Cortex-A7
CPU frequency [MHz]
1200
SIM slots quantity
1
SIM slot
Yes
Internal storage [MB]
256
Default IP address
192.168.2.1
RAM [MB]
128
Default login and password
admin / (preset password, see label/engraving)
