RF elements Symmetrical Horn Sector antenna with TwistPort, 5/6GHz, 10 dBi, 90°
Вашата цена с ДДС (20.0%)
1,076.65 RON
Поръчан за склад
Планирана Дата Доставка на Куриер до Вас 13-08-2025
Описание на продукт
Това е автоматичен превод. Оригиналния текст може да видите тук90° Symmetrical Horn Antennas have a symmetrical beam pattern with depressed sidelobes. They offer excellent noise rejection and supreme scalability options. They are perfect for high-density AP clusters and dense co-location deployments.
Key Features
- Wideband performance covering 5 & 6 GHz unlicensed spectrum bands.
- Industry-changing TwistPort™ waveguide connector. Connect directly to waveguide ported radios or use TP Adaptor to common coaxial connectors.
New Industrial design
- Built of high grade aluminum for extreme outdoor resistance including harsh salt water environments
- Extremely lightweigth for low tower load
- Compact for low wind loading
- UBR mounting bracket with stainless steel hardware with anti-seize coating
- Industry leading ergonomics with integrated handle for easy deployment
Свали
Технически параметри
LAN ports
MIMO, SISO
2 x 2
F/B ratio [dB]
28
Elevation beam width (-6dB) [°]
90
Azimuth beam width (-6dB) [°]
90
Purpose
Outdoor
Antenna gain [dBi]
10
